三菱電機小型卡式商用空調

SLZ-KA-VA2 Series - 2.5 kW - 4.6 kW

Ceiling cassette systems are an ideal option to air condition rooms where there is no available walls to mount a split system or where there is limited ceiling space for a ducted system. Its whisper quiet operation is ideal for master bedrooms, living rooms and other single room residential or commercial uses.



Features

  • 2.5 / 3/5 / 4.6 kW cooling capacity
  • 3.2 / 4.0 / 5.0 kW heating capacity
  • Compact design - fits nit a 2 metre square ceiling panel
  • 7-day programmable timer
  • Connectable to MXZ Series multi split systems

Inverter Technology
Inverter technology is your key to more comfort throughout the year, whatever the season. By controlling compressor rotation speed more precisely, inverter technology provides high-speed cooling and heating with extra energy savings compared to non-inverter models.

Compact Size for 2x2 Ceiling
The SLZ ceiling cassette series is designed to fit perfectly for 2-by-2 ceilings.


"I Feel" Control
The original one-touch Fuzzy-logic "I Feel" control memorises the ideal temperature and recreates it precisely every time.

Very Quiet Operation
The SLZ-KA25VA has a low noise level of 28 dB when cooling which makes this unit  ideal for bedrooms or living rooms.


 PAR-21MAA
7-Day Programmer
The PAR-21MAA remote controller provides the ideal room comfort featuring a weekly timer with up to 8 patterns for each calendar day. It also features: limiting the set temperature range, auto OFF timer, operation lock and multi-language display (English, Spanish, Italian, German, French, Russian, Chinese & Japanese).

2,500 Hours Long Life Filter
The built-in filter removes dust and contaminants and only needs vacuuming to maintain. The SLZ Series also feature a long life filter which can last about 2,500 hours without replacement.

Fresh Air Intake
Indoor air quality is enhanced by the direct instake of fresh exterior air.

12-Hour Timer
On/off operation can be set simultaneously in 10-minute increments for a 24-hour period.

Auto Restart
Especially useful during sudden blackouts as the unit will turn back on automatically when power is restored.

Multi-Split System Compatible
The SLZ-KA Series ceiling cassette indoor units may be connected to the Mitsubishi Electric multi-split sytem outdoor units. It is possible to mix this ceiling cassette range with other indoor unit types including wall mounted, ceiling concealed, and floor mounted.

SLZ-KA-VA ceiling cassette air conditioning system

SLZ-KA25/35/50VA

Specification Overview

Model Name   SLZ-KA25VA SLZ-KA35VA SLZ-KA50VA
Type   Inverter Inverter Inverter
Indoor Unit   SLZ-KA25VA(L)* SLZ-KA35VA(L)* SLZ-KA50VA(L)*
Outdoor Unit   SUZ-KA25VA2 SUZ-KA35VA2 SUZ-KA50VA2

Cooling
Capacity (Rated Conditions) kW 2.5 3.5 4.6
Capacity (Min - Max) kW 0.9 - 3.2 1 - 3.9 1.1 - 5.2
Air Flow (Low/Med/Hi) l/s 133-150-167 133-150-183 133-150-183
EER (Rated Conditions)   3.68 3.37 3.01
Star Rating - Original calculation   TBA TBA TBA
Star Rating - New calculation   2.5 1.5 1
Sound Pressure Levels -
Indoor at 1.5m (Low/Med/Hi) dBA 28-31-37 29-33-38 30-34-39
Outdoor at 1m dBA 46 47 53
Sound Power Level - Outdoor dBA 59 61 68

Heating
Capacity (Rated Conditions) kW 3.2 4 5
Capacity (Min - Max) kW 0.9 - 4.5 0.9 - 5 0.9 - 6.5
Air Flow (Low/Med/Hi) l/s 133-150-167 133-150-183 133-150-183
COP (Rated Conditions)   3.76 3.67 3.22
Star Rating - Original calculation   TBA TBA TBA
Star Rating - New calculation   2.5 2.5 1.5
Sound Pressure Levels -
Indoor at 1.5m (Low/Med/Hi) dBA 28-31-37 29-33-38 30-34-39
Outdoor at 1m dBA 46 48 55
Sound Power Level - Outdoor dBA 59 61 68

Indoor - Dimensions (HxWxD) mm 208 x 570 x 570 208 x 570 x 570 208 x 570 x 570
Weight - Indoor/panel kg 16.5/3 16.5/3 16.5/3

Outdoor - Dimensions (HxWxD) mm 550 x 800 x 285 550 x 800 x 285 850 x 840 x 330
Weight - Outdoor kg 30 33 53

Electrical Supply   240 volt/Single Phase/50 hertz - Outdoor Power Supply

Breaker Size A 10 10 20

Piping - max length m 20 20 30
max height m 12 12 30

Guaranteed Operating Range °C -10 - 46 -10 - 46 -10 - 43
    -15 - 24 -15 - 24 -15 - 24
